防爆L型扳手
图示-(防爆L型扳手)图片
用途：直接用于松紧六角螺栓，螺母
材质：铍铜合金，铝铜合金
|
Numvber 序号 |
S mm |
L mm |
H mm |
Be-Cu g |
A1-CU g |
|
|
1142-6 |
6 |
120 |
29 |
100 |
3 |
|
|
1142-8 |
8 |
145 |
33 |
150 |
60 |
|
|
1142-10 |
10 |
170 |
38 |
200 |
90 |
|
|
1142-12 |
12 |
215 |
42 |
220 |
135 |
|
|
1142-13 |
13 |
240 |
45 |
250 |
190 |
|
|
1142-14 |
14 |
245 |
45 |
300 |
218 |
|
|
1142-15 |
15 |
250 |
48 |
350 |
243 |
|
|
1142-16 |
16 |
255 |
48 |
500 |
290 |
|
|
1142-17 |
17 |
260 |
50 |
545 |
325 |
|
|
1142-18 |
18 |
265 |
53 |
550 |
365 |
|
|
1142-19 |
19 |
270 |
55 |
548 |
400 |
|
|
1142-20 |
20 |
275 |
58 |
600 |
450 |
|
|
1142-21 |
21 |
275 |
58 |
755 |
550 |
|
|
1142-22 |
22 |
278 |
60 |
770 |
645 |
|
|
1142-23 |
23 |
282 |
60 |
800 |
680 |
|
|
1142-24 |
24 |
286 |
60 |
850 |
700 |
|
|
1142-27 |
27 |
295 |
70 |
900 |
800 |
|
|
1142-30 |
30 |
300 |
75 |
1000 |
880 |
|
|
1142-32 |
32 |
310 |
80 |
1100 |
950 |
|
|
1142-36 |
36 |
330 |
85 |
1300 |
1150 |
|
|
1142-41 |
41 |
350 |
90 |
1410 |
1380 |
|
